■技術(shù)參數(shù)(SPECIFICATIONS)
口線數(shù)(Poles):20
口適用線規(guī)(Applicable wires):AWG30#~26#
口溫度范圍(Temperature range):-25℃~85℃
口額定電壓(Voltage rating):50V.AC/DC
口額定電流(Current rating):1.5A Max
口接觸電阻(Contact resistance):≤0.02Ω
口絕緣電阻(Insulation resistance):≥100MΩ
口耐壓(Withstand voltage):500V.AC/1min
口材料(Material):
口孔座(Houshing):PBT UL94V-0
口端子(Terminal):磷青銅
